SilverStone ATTIS 650R 650W 80+ Bronze ATX 3.1 Power Supply (SST-AT650R-BF)
SPECIFICATIONS:
|
Max. DC Output |
650W |
|
Combined +3.3V & +5V |
100W |
|
Combined +12V |
649.2W |
|
Input Voltage |
90 ~ 264 Vrms |
|
Input Frequency Range |
47Hz ~ 63Hz |
|
PFC |
Active PFC (PF>0.9 at full load) |
|
Efficiency |
82% ~ 85% (at 20% ~ 100% loading) |
|
MTBF |
100,000 hours |
|
Operating temperature |
0°C ~ 50°C |
|
Protection |
Over Power Protection Over Voltage Protection Short Circuit Protection Under Voltage Protection |
|
Connectors |
1 x 24 / 20-Pin motherboard connector 2 x 4-Pin + 4-Pin ATX 12V connectors 4 x 8 / 6-Pin PCIe connectors 6 x SATA connectors 3 x 4-Pin Peripheral connector |
|
Cooling System |
Silent 120mm fan |
|
Noise Level |
18 dBA minimum |
|
Certification |
80 PLUS Bronze |
|
Form factor |
ATX (PS2) |
|
Dimension |
150mm (W) × 86mm (H) × 140mm (D) 5.91" (W) x 3.39" (H) x 5.5" (D) |
|
Weight |
1.52 kg |
Original: $52.42
-70%$52.42
$15.73
Description
SPECIFICATIONS:
|
Max. DC Output |
650W |
|
Combined +3.3V & +5V |
100W |
|
Combined +12V |
649.2W |
|
Input Voltage |
90 ~ 264 Vrms |
|
Input Frequency Range |
47Hz ~ 63Hz |
|
PFC |
Active PFC (PF>0.9 at full load) |
|
Efficiency |
82% ~ 85% (at 20% ~ 100% loading) |
|
MTBF |
100,000 hours |
|
Operating temperature |
0°C ~ 50°C |
|
Protection |
Over Power Protection Over Voltage Protection Short Circuit Protection Under Voltage Protection |
|
Connectors |
1 x 24 / 20-Pin motherboard connector 2 x 4-Pin + 4-Pin ATX 12V connectors 4 x 8 / 6-Pin PCIe connectors 6 x SATA connectors 3 x 4-Pin Peripheral connector |
|
Cooling System |
Silent 120mm fan |
|
Noise Level |
18 dBA minimum |
|
Certification |
80 PLUS Bronze |
|
Form factor |
ATX (PS2) |
|
Dimension |
150mm (W) × 86mm (H) × 140mm (D) 5.91" (W) x 3.39" (H) x 5.5" (D) |
|
Weight |
1.52 kg |
